1783-ZMS8TA Allen Bradley Redundant Power Supply Module 12 VDC At 150 MA

1783-ZMS8TA Allen Bradley Redundant Power Supply Module 12 VDC At 150 MA

1783-ZMS8TA Description

1783-ZMS8TA Key Features

• 8 Fast Ethernet Ports: 8×10/100 Mbps auto‑sensing copper ports for flexible device connection.
• Rugged IP67/NEMA Type 4 Enclosure: Dust‑tight and water‑submersible protection for harsh industrial and outdoor use.
• Extended Temperature Operation: −40 °C to +60 °C for extreme environment reliability.
• Fan‑less Design: Eliminates moving parts, reduces maintenance, and prevents dust ingress.
• Device‑Level Ring (DLR) Support: Enables fast network recovery (<50 ms) for redundant topologies.
• Dual Power Input: 12–48 V DC wide‑range voltage with redundancy for uninterrupted operation.
• Advanced Management Features: VLAN, QoS, SNMP, and port security for optimized network performance.
• SD Card Configuration: Simplifies device replacement and backup/restore of settings.
• Alarm Relay Output: Provides external notification for fault conditions.
• High EMI Immunity: Compliant with industrial EMC standards for noise‑prone environments.

1783-ZMS8TA Materials & Applications

Materials

• Housing: Heavy‑duty die‑cast aluminum alloy with powder coating, providing mechanical strength, corrosion resistance, and IP67 sealing.
• Internal Components: Industrial‑grade electronic components with conformal coating for moisture and chemical resistance.
• Connectors: IP67‑rated sealed Ethernet and power connectors for secure, vibration‑proof wiring.
• PCB: High‑temperature glass‑epoxy laminate with gold‑plated contacts for signal integrity and reliability.

Typical Applications

• Automotive Manufacturing: Robotic cell networking, welding lines, and assembly floor communication.
• Oil & Gas: Refineries, offshore platforms, and hazardous area network connectivity.
• Food & Beverage: Clean‑in‑place (CIP) zones, packaging lines, and sanitary environment networking.
• Energy & Utilities: Power substations, renewable energy sites, and water treatment plants.
• Outdoor & Transportation: Railway systems, traffic control, and industrial IoT edge deployments.

1783-ZMS8TA Important Parameters
